BACnet Thermostat
 |
EXL01625 BACnet Fan Coil Units Modulating Heat and Cool |
- Fan Coil Units
- BACnet Communications
- Modulating Heating
- Analog 0-10Vdc, 0-5Vdc, 2-10Vdc, 1-5Vdc
- Modulating with Power Open/Close PO/PC
- Modulating Cooling
- Analog 0-10Vdc, 0-5Vdc, 2-10Vdc, 1-5Vdc
- Modulating with Power Open/Close PO/PC
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01627 BACnet Fan Coil Unit, Reheat Coil, Underfloor VAV |
- BACnet communications
- Operates Fan Coil Units, Reheat Coils, Underfloor VAV zones etc.
- Operates Fan Coils with a four pipe system
- Fan Coil Units
- Modulating Fan Speed - 0-10Vdc, 0-5Vdc, 2-10Vdc
- Modulating Heating or Cooling - 0-10Vdc, 0-5Vdc, 2-10Vdc
- Floating Heating and Cooling - Power Open/Close PO/PC
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01629 BACnet Fan Coil 3 speed fan with Dehumidification |
- Fan Coil Units
- BACnet Communications
- Modulating Heating & Cooling
- 3 Speed Fan
- Discharge Air Reset
- Dehumidification Mode
- External Dehumidification
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01630 BACnet Display |
- Displays BACnet variables
- Provides Status
- Allows Adjustment
- Change display descriptors to display different values.
- Provides access to MS/TP communication port for Portable Operators Terminal
- Optional MS/TP communications plug with cable is required for a proper connection
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01640 BACnet Unit Heater Infloor Heat Radiant Heaters |
- BACnet communiccations
- Unit Heaters
- Cabinet Unit Heaters
- Infloor Heat
- Radiant Heaters
- Baseboard Radiation
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01641 BACnet Unit Heater Infloor with Staged and Modulating Heat |
- First stage digital and second stage analog, heat only.
- BACnet communications
- Unit Heaters
- Cabinet Unit Heaters
- Infloor Heat
- Radiant Heaters
- Baseboard Radiation
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01642 BACnet Unit Heater Infloor Heat with Aquastat Function |
- BACnet communications
- Operates Unit Heater, Cabinet Unit Heaters, Infloor heat, and other heating
applications
- Unit/Cabinet Heater with Aqua Stat function
- Digital/Infloor Heating
- Floating point, 0-10 VDC, 10-0 VDC Heating Valve Control, Binary Open, and Binary Closed
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01643 BACnet Multizone Heating |
- Multi Zone Heat
- Four Zone Space Temperature Monitoring
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01645 BACnet California Title 24 (T-24) Energy Code Controller |
- BACent communications
- California Title 24(T-24) Energy Code
- Heating limited to 55°F for process space control
- Heat on at 40°F, Heat off at 55°F, hard coded
- 2-Stage Heat Command
- 0-10 VDC Modulating Heat Command
|
|
|
|
Your Price: $158.00 |
 |
|
 |
EXL01646 BACnet California Title 24 (T-24) 140.4 with Door Interlock |
- BACnet communication
- California Title 24(T-24) 140.4 Energy Code Mechanical Interior
- Heating limited to 55°F when interlocked doors and windows are open
- 2-Stage Heat Command
- 0-10 VDC Modulating Heat Command
|
|
|
|
Your Price: $158.00 |
 |
|
|
